5XT
Good things in small packages
2-way passive, 5"
| Max SPL | 121 dB |
| Bandwidth | 95 Hz- 20 KHz |
| Transducers | LF : 1 x 5" HF : 1 x 1" |
| Weight | 3.5 kg / 7.7 lb |
| Directivity | H: 110° V: 110° |
Inspiration
Janet Jackson Extends Her Landmark Las Vegas Residency, Featuring L-Acoustics L-ISA Hyperreal Immersive Sound Technology
Netherlands’ NBC Congrescentrum Creates Adaptive Sound Design Experience with L-Acoustics K Series
Bedok Methodist Church Selects L-Acoustics A Series After Rigorous Four-Week Shootout
Need more information?
Check out our Documentation Center for more documents on this product.
Electroacoustic specs
2-way passive coaxial enclosure
amplified by LA2Xi / LA4X / LA8 / LA12X
| Usable bandwidth (-10 dB) | 95 Hz – 20 kHz ([5XT]) |
| Maximum SPL1 | 121 dB ([5XT]) |
| Nominal directivity (-6 dB) | 110° axisymmetric |
| Transducers | LF: 1 × 5″ cone driver |
| Acoustical load | bass-reflex |
| Nominal impedance | 16 Ω |
1 Peak level measured at 1 m under free field conditions using pink noise with crest factor 4 (preset specified in brackets).
Physical specs
| Connectors | IN: 1 × 4-point speakON |
| Rigging and handling | 2 M6 inserts for ETR5 |
| Weight (net) | 3.5 kg / 7.7 lb |
| Cabinet | premium grade Baltic birch plywood |
| Front | steel with anti-corrosion coating |
| Finish | dark grey brown Pantone 426 C |
| IP | IP30 |
Dimensions
