L2D
The Sound. The Shape. The Future.
16-channel PULS for medium and large size events
| Max SPL | 151 dB |
| Bandwidth | 45 Hz- 20 KHz |
| Transducers | LC: 4 x 12" LF: 8 × 10’’ HF: 8 × 3’’ |
| Weight | 149 kg / 328 lb |
| Directivity | V: 60° H: Top two modules Panflex:70° / 90° / 110° Bottom two modules progressive 110° to 140° Integrated cardioid |
Inspiration
Mazowsze National Ensemble Unveils State-of-the-Art 360° L-ISA Immersive Hyperral Sound Experience Using the New L-Acoustics L Series
Brisbane Sound Group Becomes Australia’s First L-Acoustics L Series Rental Partner
Unreal-Systems Deploys L-Acoustics L Series Concert Sound System for John Summit’s Three-Night, Sold-Out Run at L.A.’s Kia Forum
Need more information?
Check out our Documentation Center for more documents on this product.
Electroacoustic specs
16-channel active progressive curvature WST®
amplified by LA7.16/LA7.16i
| Usable bandwidth (-10 dB) | 45 Hz – 20 kHz ([L2 70]) |
| Maximum SPL1 | Full element: 151 dB ([L2 70]) First module: 147 dB ([L2 70]) |
| Nominal directivity (-6 dB) | vertical: 60° progressive directivity horizontal: Integrated cardioid |
| Transducers | LC: 4 × 12’’ neodymium cone drivers |
| Acoustical load | LC/LF: Bass-reflex, L-Vents |
| Nominal impedance | LC : 8 Ω |
1 Peak level measured at 1 m under free field conditions using pink noise with crest factor 4 (preset specified in brackets).
Physical specs
| Connectors | 1 x 37-point male connector (32 points used) |
| Rigging and handling | flush-fitting 4-point captive rigging system compatible with L2D |
| Weight (net) | 149 kg / 328 lb |
| Cabinet | premium grade Baltic birch plywood |
| Front | coated steel grill |
| Rigging components | high grade steel with anti-corrosion coating |
| Finish | dark grey brown Pantone 426 C |
| IP | IP55 |
Dimensions
