Products
Electronics
Amplified controllers
LA7.16
  • Overview
  • Full specs
  • System Elements
  • Downloads
Overview
Overview Full spec System Elements Downloads
  1. Front
  2. Back
  3. Side

LA7.16

Multi-channel amplified controller

Architecture 16 x 16
Output Power 16 x 700 W at 16 ohms
16 x 1300 W at 8 ohms
16 x 1100 W at 4 ohms
Power supply Universal SMPS with PFC
Inputs Milan-AVB, AES/EBU, Analog
Network Milan-certified with seamless network redundancy
Q-SYS

Inspiration

La Villette Transforms Historic Space into Immersive Audio Experience for Diverse Performances with L-Acoustics L-ISA Hyperreal Immersive Sound featured image
La Villette Transforms Historic Space into Immersive Audio Experience for Diverse Performances with L-Acoustics L-ISA Hyperreal Immersive Sound
KS28
L Series
L-ISA
L-ISA Immersive
L2
L2D
LA12X
LA4X
LA7.16
X12
X8i
L-Acoustics L Series Helps Make the Junos an Awarding Experience featured image
L-Acoustics L Series Helps Make the Junos an Awarding Experience
A15
K2
KARA II
KS28
L Series
L2
L2D
LA12X
LA7.16
P1
SB18
X15
L-Acoustics L-ISA Hyperreal Technology Optimizes Sound Localization and Clarity at Israel Expo Centre’s Tozeret Haaretz Series featured image
L-Acoustics L-ISA Hyperreal Technology Optimizes Sound Localization and Clarity at Israel Expo Centre’s Tozeret Haaretz Series
KARA II
KARA/KS28
KS28
L-ISA
L-ISA Controller
L-ISA Immersive
L-ISA Processor II
L2
L2D
LA12X
LA7.16
SYVA
See all news

Related Products

Previous Previous Next Next
background image
LA Network Manager
background image
Milan Manager
background image
LS10
background image
LA-RAK III
background image
L2
background image
L2D
background image
LA Network Manager
background image
Milan Manager
background image
LS10
background image
LA-RAK III
background image
L2
background image
L2D

Related Trainings

Previous Previous Next Next
background image
System & Workflow
background image
Drive System
background image
L-Acoustics System Implementation
background image
L2 System
background image
background image
background image
background image

Need more information?

Check out our Documentation Center for more documents on this product.

Go to documentation center
Amplification and power supply
DSP
Technologies
Latency
Inputs
Outputs
Circuits protection
Interface
Remote control and monitoring
Operating conditions
Physical data

Amplification and power supply

Amplification class High-efficiency class D
Output power, all channels loaded 16 x 1100 W at 4 ohms
16 x 1300 W at 8 ohms
16 x 700 W at 16 ohms
nominal power requirements 16 A (200-240 V) 30 A (100-120 V)
mains connector 32 A powerCON
Power supply model Universal Switched Mode Power Supply (SMPS) with Power Factor Correction (PFC)
Mains rating 100 V - 240 V ±10%, 50-60 Hz
External DSP backup voltage input 24 V DC

DSP

Digital Signal Processor (DSP) Gen.5 Dual SHARC 32-bit, floating point, 96 kHz sampling rate
I/O routing 16 x 16 routing and summation matrix
Per output channel Built-in EQ station with 8 IIR, 4 FIR linear phase EQ filters
Array morphing (LF contour, zoom factor), Air absorption compensation filters
Internal IIR and FIR EQ algorithms for speaker phase linearization and improved impulse responses
Output delay from 0 to 1000 ms

Technologies

loudspeaker management L-DRIVE advanced system protection
amplifier management L-SMART adaptative power management

Latency

standard latency (analog/digital inputs) 3.84 ms
low latency (analog/digital inputs) 1.18 ms

Inputs

Milan-AVB 16 channels from up to 16 streams (of up to 8 channels each)
AES/EBU 2 channels AES/EBU (1 x AES3) with SRC
analog 1 channel analog
connections 2 etherCON 1 Gb/s I/O+ control 1 male 12-point terminal block (AES3 or Ana input/link + GPIO)

Outputs

loudspeaker connections 1 SC32 connector

Circuits protection

Mains and power supply Over and under voltage / over temperature / overcurrent
Power outputs Overcurrent / DC / short circuit / over temperature

Interface

display/indicators 1 TFT color touchscreen display (480 × 128 px)
Display 1 encoding wheel with push button

Remote control and monitoring

L-Acoustics remote control software LA Network Manager
General purpose inputs and outputs (GPIO) 3 in/out on 12 point terminal block
Third-party management solutions Q-SYS® / Crestron®

Operating conditions

Temperature -5º C / 23º F to +50º C / 122º F

Physical data

Height 2U
Weight 15.8 kg / 34.8 lb

Dimensions

LA7.16 schema
