LS10
AVB Switch, Avnu-certified
| Architecture | 10-port Ethernet AVB |
| Ethernet ports |
8 EtherCONTM 1 Gb/s 2 SFP cages 1 Gb/s |
| Height x Width | 1U x 1/2 U |
| Power |
IEC inlet with V-lockTM 24 V DC redundant I/O power |
| Management | gPTP priority, RSTP |
| GPO | General fault indication |
Inspiration
Need more information?
Check out our Documentation Center for more documents on this product.
Power supply
| Mains rating | 100 V - 240 V ( ±10%), 50-60 Hz |
| connector | lockable IEC connector C13 |
| Power consumption | 10 W - 20 W max when powering another LS10 |
| Backup power circuit | 24 V DC redundant power input 24 V DC redundant power output |
Interface
| indicators | 1 LED for power status, 1 LED for fault status 10 LEDs for link/act status |
| button | reset to factory settings |
Remote control and monitoring
| L-Acoustics remote control software | LA Network Manager |
| General purpose inputs and outputs (GPIO) | 1 user-configurator GPO |
Operating conditions
| Temperature | -5º C / 23º F to +50º C / 122º F |
Network
| Ethernet ports | 10 AVB ports at 1 Gb/s: - 8 x Neutrik etherCONTM I/O (5 in the front, 3 in the back) - 2 × SFP cages (rear) |
| Featured AVB entities | Avnu-certified AVB bridge |
| Standards | IEEE 802.1BA-2011 standard augmented by Avnu ProAV 1.1 requirements |
| Number of supported AVB streams | 150 |
| Startup time | Ready to forward AVB streams in 5 seconds |
Ethernet port features
| Management | gPTP grandmaster capable, priority selection RSTP: enable/disable |
| Port sensing | Auto negotiation |
| Auto crossover | MDI / MDIX (allows to use straight or cross cables) |
| Autosensing | Full or Half Duplex (Gigabit is always Full Duplex Mode) |
Physical data
| Height | 1U |
| Weight | 1.5 kg / 2.2 lb |
| Protection rating | IP30 |
Dimensions
