SB18
High-power subwoofer, 18"
| Max SPL | 138 dB |
| Low frequency limit | 32 Hz |
| Transducers | LF: 1 x 18" |
| Weight | 52 kg / 115 lb |
| Directivity | standard or cardioid configurations |
POWERFUL
High-power handling and high-excursion driver for maximized output and bandwidth
SHARP
Clear low-frequency power with L-VENTS™
RUGGED
Built for the road with simple, fast, integral rigging
Inspiration
Need more information?
Check out our Documentation Center for more documents on this product.
Electroacoustic specs
High power compact subwoofer: 1 x 18''
amplified by LA4X / LA8 / LA12X
| Low frequency limit (-10 dB) | 32 Hz ([SB18_100]) |
| Maximum SPL1 | 138 dB ([SB18_100]) |
| Nominal directivity (-6 dB) | standard or cardioid |
| Transducers | 1 × 18″ |
| Acoustical load | dual bass-reflex, L-Vents |
| Nominal impedance | 8 Ω |
1 Peak level at 1 m under half space conditions using pink noise with crest factor 4 (preset specified in brackets).
Physical specs
| Connectors | 2 × 4-point speakON |
| Rigging and handling | 4 x handles |
| Weight (net) | 52 kg / 115 lb |
| Cabinet | premium grade Baltic birch plywood |
| Front | coated steel grill |
| Rigging components | steel with anti-corrosion coating |
| Finish | dark grey brown Pantone 426 C |
| IP | IP55 |
